TECHNOLOGY
Sales and Engineering Departments
Advanced Integrated Manufacturing Software
Barcode Interface
Computerized Production Planning System
Computerized Sales Management System
SI 6000b Controlled Impedance Design System
Photoplotting Department
2 Stations Orbotech Genesis 2000 CAM Software and CAM 350
EIE RP362-DL Dual-Auto Loader Raster Photoplotter
Glunz & Jensen 28” Film Processor
Programming, Drilling & Fabrication Departments
Ceco Hole Checker 8 Auto Inspection
3 Excellon Mark VII Driller
1 Excellon Concept 4
Excellon EX 300 Driller/Router
Excellon EX 200 Driller/Router
Excellon Mark V Driller/Router
1 Excellon Concept 129 Single spindle with built in x-ray camera (180k RPM)
1 Excellon 689 six spindle (180k RPM)
Accuscore Scoring Machine
Automatic Stacking Machine
Glenn Brook Real Time x-ray
DNC File Server
Bevelers, Edgemate, Shear Machine
Dry Film and Photo Departments
Multiline Semi-Automatic Artwork Punch
Multiline Automatic Post-Etch Punching of Inner Layers
4 Multiline Glass Phototools
ORC Exposure Unit 8kW
2 ORC Exposure Unit 5kW
2 Hakuto Mach 610I Auto Cut-Sheet Laminator
3 Western Magnum Substrate Cleaner Line
Chemcut 547 Semi-Automatic Developer
Multi-Layer Lamination Department
2 Fully Automated TMP Four Opening Vacuum Lamination Press
2 TMP Cold Presses
Wabash Two Opening Vacuum Lamination Press (20x26)
Complete Multiline Registration System
Multiline De-Pinner
Plating Department
March Plasma System
Potassium Permanganate De-Smear Line
Semi-Automatic Electroless Copper Line
1 1500 gallon Dual Rectification Electroplating Copper Tank
2 1000 Gallon Electro Plating Eductor Copper Tanks
1000 Gallon Tin Tank
Chemcut Semi-Automatic Conveyorized Oxide Line
Chemcut Semi-Automatic Conveyorized Dryfilm Chem-Chemcut
Inner layer clean line
DES (develop/etch/strip)
Oxide Replacement
Film stripper
Ammonia etcher
Tin stripper
Semi-Automatic Stripping Line
Chemcut Semi-Automatic Conveyorized Etching Machines
Chemcut Semi-Automatic Conveyorized Tin Stripper
Technic Auto Gold Line
Double-Sided Scrubber/Deburrer Dryer Units
Cemco Pre-Clean and Flux Coater
Quick Silver SM Hot Air Solder Coater Machine
Marseco Semi-Automatic Post Cleaner System
Kenetic Ionic Exchange Fully Automated Computerized Wastewater Treatment System
Vertical Cemco Hot Air Leveler
Immersion silver plating line
Soldermask/Silkscreen Departments
DP-1500-2X Dual Sided LPI Soldermask Coater
TC-150 Conveyorized Oven
TC-120 Conveyorized Oven
OLEC AP30CL-8000
NuArc Flip Top 4K
Grieve SC-350 82x64x32 Oven
Proheatco 82”x64”x42” Oven
Chemcut 547 Semi-Automatic Developer
3 24”x30” Screen Tables
24” I.S. Pumice Scrubber Dryer
Western Magnum Substrate Clean Line
Complete Load and Unload System
New Systems New Print Auto Legend
Quality Control Department
Mil-PRF-55110 with Etchback
ISO 9001:2000 Registered
Polar Inst. CITS 500s Controlled Impedance
(TDR) Test System
ATG A5 Flying Probe Test System
3 New System S24-25AC Flying Grid Tester w/720
3 Camtek Orion 604 WR
Gerber 20/20 Automatic Optical Inspection (AOI)
Fastek Bare Board Tester Model 110
Fastek Bare Board Tester Model 160
Buehler Cross-Section Laboratory
Olympus Microscope with Photo
CMI PTX Series for Measuring Copper Thickness
Oxford Instruments CMI900 XRF - XRay Fluorescence
for measuring gold/nickel, silver and palladium
Complete chemical analysis laboratory
CVS unit including automatic chemical analysis
ISO 9001:2000
See our Certificate of Registration
Mil-PRF-55110F
See our Certificate of Registration
U.S. Circuit Purchases Two Excellon Systems
The Concept 129 Intelli-Drill™ combines the accuracy and ease of use of the Concept 129 family with the ability to inspect and correct for inner layer registration errors.
-More
-
